product description
MikroTik Cloud Core Router CCR-1016-12G - Revision 2
CCR1016-12G is an industrial grade router with a cutting edge 16 core CPU. If you need many millions of packets per second - Cloud Core Router is your best choice. Unit is equipped with 12 x Gigabit Ethernet ports and color touchscreen LCD.
The new r2 version has onboard 2GB of RAM, full size USB slot and dual PSU for redundancy!
-
shipped with:
- Rack ears
- 2x IEC Cords (Kaltgerätekabel)
- K-57 Kit (Schraubenset)
-
Links:
- brochure: https://i.mt.lv/cdn/product_files/ccr1016-12G_210511.pdf
- guide: https://help.mikrotik.com/docs/display/QG/Quick+Guide+G1-b
- manual: https://help.mikrotik.com/docs/display/UM/CCR1016-12G
- routerboot firmware: https://i.mt.lv/cdn/rb_bootloaders/tilegx_3.41.fwf
- diagramm r2: https://i.mt.lv/cdn/product_files/CCR1016-12Gr2_200453.png
- diagramm: https://i.mt.lv/cdn/product_files/CCR1016-12G-160219130439_160239.png
- wiki: https://wiki.mikrotik.com/wiki/Manual:TOC
- CE: https://i.mt.lv/cdn/product_files/ID043_CCR1016-12G_CCR1016-12S-1S_DOC_210730.pdf
-
Specifications
| Details | |
|---|---|
| Product code | CCR1016-12G |
| Architecture | TILE |
| CPU | TLR4-01680 |
| CPU core count | 16 |
| CPU nominal frequency | 1.2 GHz |
| Dimensions | 443 x 193 x 44 mm |
| RouterOS license | 6 |
| Operating System | RouterOS |
| Size of RAM | 2 GB |
| Storage size | 512 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -20°C to 60°C |
| IPsec hardware acceleration | Yes |
Powering
| Details | |
|---|---|
| Number of AC inputs | 2 |
| AC input range | 100-240 |
| Max power consumption | 42 W |
| Max power consumption without attachments | 37 W |
| FAN count | 2 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 12 |
Peripherals
| Details | |
|---|---|
| Serial console port | RJ45 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | USB type A |
| Max USB current (A) | 1 |
Other
| Details | |
|---|---|
| CPU temperature monitor | Yes |
| PCB temperature monitor | Yes |
| Mode button | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, EAC, ROHS |
| IP | IP20 |
-
Ethernet test results
| CCR1016-12Gr2 | Tile 16 core max possible throughput test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 975,2 | 11842,8 | 2819,5 | 11548,7 | 17857,1 | 9142,8 |
| Bridging | 25 bridge filter rules | 975,2 | 11842,8 | 2120,8 | 8686,8 | 2819,5 | 1443,6 |
| Routing | none (fast path) | 975,2 | 11842,8 | 2819,5 | 11548,7 | 17857,1 | 9142,8 |
| Routing | 25 simple queues | 975,2 | 11842,8 | 2610,4 | 10692,2 | 2787,7 | 1427,3 |
| Routing | 25 ip filter rules | 975,2 | 11842,8 | 1253,4 | 5133,9 | 1316 | 673,8 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
IPsec test results
| CCR1016-12Gr2 | CCR1016 series IPsec throughput | ||||||
| Mode | Configuration | 1400 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Single tunnel | AES-128-CBC + SHA1 | 130.5 | 1461.6 | 123.4 | 505.4 | 115.4 | 59.1 |
| 256 tunnels | AES-128-CBC + SHA1 | 363.8 | 4074.6 | 413.8 | 1694.9 | 425.9 | 218.1 |
| 256 tunnels | AES-128-CBC + SHA256 | 357.6 | 4005.1 | 399.2 | 1635.1 | 425.9 | 218.1 |
| 256 tunnels | AES-256-CBC + SHA1 | 354.9 | 3974.9 | 399.2 | 1635.1 | 425.9 | 218.1 |
| 256 tunnels | AES-256-CBC + SHA256 | 348.0 | 3897.6 | 384.6 | 1575.3 | 403.8 | 206.7 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1400 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
Downloads
ccr1016-12G-rev2-declaration-ce.pdf (0.11 MB)
ccr1016-12G-rev2-quickguide.pdf (0.24 MB)
ccr1016-12G-rev2-brochure.pdf (0.55 MB)
