Teltonika PR5MEC15 - CONNECTORS SET
Art.Nr.: PR5MEC15
Hersteller: Teltonika
4,64 EUR
incl. 19 % USt
-
Sofort versandfähig, geringe Stückzahl
- Lieferzeit sofort lieferbar
- Gewicht 0,01 kg
Produktbeschreibung
#1: PR5MEC15
CONNECTORS SET
#2: Im Lieferumfang enthalten
- 1x PR5MEC15
#3: Features
2X5 PIN CONNECTOR
-
GENERAL
-
Voltage rating
300 V
-
Current rating
8 A
-
Withstand voltage
1600 V/1min
-
Wire range AWG
16 – 24 AWG
-
Operating temperature
–40 °C ~ +105 °C
-
Insulation material
PA66
-
Internal contacts material
Copper alloy
-
Internal contacts finishing
Sn plated
-
ADDITIONAL
-
Strip Length
9 – 10 mm
-
Pitch
3.5 mm
-
Shrapnel material
Stainless steel
-
Conductor cross section
0.2 – 1.5 mm²
-
Poles
2 x 5
-
Flammability rating
UL 94 V-0
-
RoHS
✓
-
REACH
✓
2X3 PIN CONNECTOR
-
GENERAL
-
Voltage rating
300 V
-
Current rating
8 A
-
Withstand voltage
1600 V/1min
-
Wire range AWG
16 – 24 AWG
-
Operating temperature
–40 °C ~ +105 °C
-
Insulator material
PA66
-
Internal contacts material
Copper alloy
-
Internal contacts finishing
Sn plated
-
ADDITIONAL
-
Strip Length
9 – 10 mm
-
Pitch
3.5 mm
-
Shrapnel material
Copper alloy
-
Conductor cross section
0.2 – 1.5 mm²
-
Poles
2 x 3
-
Flammability rating
UL 94 V-0
-
RoHS
✓
-
REACH
✓
Downloads
connectors-set-pr5mec15.pdf (0.35 MB)
