MikroTik RB911-5HacD - 911 Lite5 ac

Name: MikroTik RB911-5HacD - 911 Lite5 ac
Brand: MikroTik
SKU: RB911-5HacD
Price: 46.9 EUR
Availability: OutOfStock

Art.Nr.: RB911-5HacD

Hersteller: MikroTik

46,90 EUR
incl. 19 % USt

zzgl. Versandkosten

Zur Zeit nicht lagernd, bitte per E-Mail anfragen.
Lieferzeit End of Life - EoL - Nichtmehr lieferbar!
Gewicht 0,2 kg

Produktbeschreibung

#1: RB911-5HacD - 911 Lite5 ac

Perfekt für den Aufbau kostengünstiger CPE-Geräte. Der RB911-5HnD ist ein kleiner CPE RouterBOARD Wireless Router mit einer integrierten 5Ghz Dual Chain Wireless Karte. Er ist mit einer leistungsstarken 600MHz CPU ausgestattet und bietet ein hervorragendes Preis-Leistungs-Verhältnis.

Der RB911-5HnD (International) unterstützt den Frequenzbereich von 5150MHz-5875MHz (Der spezifische Frequenzbereich kann durch länderspezifische Vorschriften eingeschränkt sein).

#2: Im Lieferumfang enthalten

1x RB911-5HacD (911 Lite5 ac)

#3: Spezifikationen - Technische Details

Details
Product code	RB911-5HnD
Architecture	MIPSBE
CPU	AR9344
CPU core count	1
CPU nominal frequency	600 MHz
Dimensions	105x105mm
RouterOS license	3
Operating System	RouterOS
Size of RAM	64 MB
Storage size	16 MB
Storage type	FLASH
MTBF	Approximately 100'000 hours at 25C
Tested ambient temperature	-40°C to 70°C

Powering

Details
Number of DC inputs	1 (PoE-IN)
Max power consumption	7 W
Cooling type	Passive
PoE in	Passive PoE
PoE in input Voltage	6-30 V

Wireless specifications

Details
Wireless 5 GHz Max data rate	300 Mbit/s
Wireless 5 GHz number of chains	2
Wireless 5 GHz standards	802.11a/n
Wireless 5 GHz chip model	AR9344
Wireless 5 GHz generation	Wi-Fi 4

Ethernet

Details
10/100 Ethernet ports	1

Certification & Approvals

Details
Certification	CE, FCC, IC, EAC, ROHS
IP	IP00

Wireless specifications

5 GHz	Transmit (dBm)	Receive Sensitivity
6MBit/s	26	-96
54MBit/s	22	-77
MCS0	26	-96
MCS7	21	-71

#4: Test-Resultate nach RFC2544

Ethernet test results

RB911-5HnD		AR9344 100M 1 port test
Mode	Configuration	1518 byte		512 byte		64 byte
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	8.1	98.4	23.5	96.3	148.0	75.8
Bridging	25 bridge filter rules	8.1	98.4	23.5	96.3	87.6	44.9
Routing	none (fast path)	8.1	98.4	23.5	96.3	148.0	75.8
Routing	25 simple queues	8.1	98.4	23.5	96.3	106.6	54.6
Routing	25 ip filter rules	8.1	98.4	23.5	96.3	60.5	31.0

All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
