MikroTik CRS125-24G-1S-2HnD-IN
Art.Nr.: CRS125-24G-1S-2HnD
Hersteller: MikroTik
243,95 EUR
incl. 19 % USt
-
Zur Zeit nicht lagernd, bitte per E-Mail anfragen.
- Lieferzeit End of Life - Discontinued - Nichtmehr lieferbar!
- Gewicht 1,5 kg
Produktbeschreibung
#1: CRS125-24G-1S-2HnD-IN
Der Cloud Router Switch gehört zur Mikrotiks Smart Switch Serie. Er kombiniert die besten Eigenschaften eines voll funktionsfähigen Routers und eines Layer-3-Switches und wird durch das bekannte RouterOS betrieben. Alle spezifischen Switch-Konfigurationsoptionen sind in einem speziellen Switch-Menü verfügbar, aber wenn Sie möchten, können Ports aus der Switch-Konfiguration entfernt und für Routing-Zwecke verwendet werden.Darüber hinaus verfügt dieses Gerät über einen integrierten 2,4-GHz-Wireless-Access-Point, d. h. Sie können einen AP, einen Router mit einer beliebigen Anzahl von Ports und einen Smart-Switch mit voller Leitungsgeschwindigkeit in einem Gerät nutzen - ideal für mittlere/kleine Unternehmen und Büros. Er verfügt über 24 Gigabit-Ports, einen SFP-Cage, einen microUSB-Port und einen eingebauten Wireless-AP.
Perfekter SOHO-Gateway-Router, Switch und 802.11n-AP in einem Gerät
- Ethernet-, Glasfaser- oder 4G-Gateway-Verbindung (mit optionalem USB-Modem) zum Internet
- RouterOS-Gateway/Firewall/VPN-Router mit passiver Kühlung
- Bis zu 25 Gigabit-Switch-Ports (1xSFP und 24xRJ45)
- Leistungsstarker 2,4GHz 802.11n Wireless AP
#2: Im Lieferumfang enthalten
- 1x CRS125-24G-1S-2HnD-IN
- 1x 24V 1.2A power adapter
- 1x USB OTG cable
#3: Spezifikationen - Technische Details
| Details | |
|---|---|
| Product code | CRS125-24G-1S-2HnD-IN |
| Architecture | MIPSBE |
| CPU | AR9344 |
| CPU core count | 1 |
| CPU nominal frequency | 600 MHz |
| Switch chip model | QCA8513 |
| Dimensions | 285 x 167 x 44 mm |
| RouterOS license | 5 |
| Operating System | RouterOS |
| Size of RAM | 128 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| MTBF | Approximately 200'000 hours at 25C |
| Tested ambient temperature | -30°C to 60°C |
Powering
| Details | |
|---|---|
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input Voltage | 8-28 V |
| Max power consumption | 19 W |
| Cooling type | Passive |
| PoE in | Passive PoE |
| PoE in input Voltage | 8-28 V |
Wireless specifications
| Details | |
|---|---|
| Wireless 2.4 GHz Max data rate | 300 Mbit/s |
| Wireless 2.4 GHz number of chains | 2 |
| Wireless 2.4 GHz standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 4 |
| Wireless 2.4 GHz chip model | AR9344 |
| Wireless 2.4 GHz generation | Wi-Fi 4 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 24 |
Fiber
| Details | |
|---|---|
| SFP DDMI | Yes |
| SFP ports | 1 |
Peripherals
| Details | |
|---|---|
| Serial console port | RJ45 |
| Number of USB ports | 1 |
| USB Power Reset | Yes |
| USB slot type | microUSB type AB |
| Max USB current (A) | 1 |
Other
| Details | |
|---|---|
| PCB temperature monitor | Yes |
| Voltage Monitor | Yes |
| Beeper | Yes |
Certification & Approvals
| Details | |
|---|---|
| Certification | CE, FCC, EAC, ROHS |
| IP | IP20 |
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive Sensitivity |
|---|---|---|
| 1MBit/s | 29 | -97 |
| 11MBit/s | 28 | -90 |
| 6MBit/s | 30 | -96 |
| 54MBit/s | 25 | -76 |
| MCS0 | 30 | -96 |
| MCS7 | 23 | -73 |
#4: Test-Resultate nach RFC2544
Switching results
| CRS125-24G-1S-2HnD-IN | |||||||
|---|---|---|---|---|---|---|---|
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Switching | Non blocking Layer 2 throughput | 2,031.9 | 24,674.9 | 5,874.1 | 24,060.2 | 37,202.4 | 19,047.6 |
| Switching | Non blocking Layer 2 capacity | 2,031.9 | 49,349.8 | 5,874.1 | 48,120.3 | 37,202.4 | 38,095.2 |
| Switching | Non blocking Layer 1 throughput | 2,031.9 | 25,000.0 | 5,874.1 | 25,000.0 | 37,202.4 | 25,000.0 |
| Switching | Non blocking Layer 1 capacity | 2,031.9 | 50,000.0 | 5,874.1 | 50,000.0 | 37,202.4 | 50,000.0 |
Ethernet test results
| CRS125-24G-1S-2HnD-IN | AR9344 1G all port test | ||||||
| Mode | Configuration | 1518 byte | 512 byte | 64 byte | |||
| kpps | Mbps | kpps | Mbps | kpps | Mbps | ||
| Bridging | none (fast path) | 81.0 | 983.7 | 232.0 | 950.3 | 269.6 | 138.0 |
| Bridging | 25 bridge filter rules | 81.0 | 983.7 | 86.0 | 352.3 | 87.6 | 44.9 |
| Routing | none (fast path) | 81.0 | 983.7 | 210.0 | 860.2 | 226.9 | 116.2 |
| Routing | 25 simple queues | 81.0 | 983.7 | 103.9 | 425.6 | 106.6 | 54.6 |
| Routing | 25 ip filter rules | 56.8 | 689.8 | 59.6 | 244.1 | 60.5 | 31.0 |
- All tests are done with Xena Networks specialized test equipment (XenaBay),and done according to RFC2544 (Xena2544)
- Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
- Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
The device has an operating system preinstalled and licensed. No separate purchase is necessary and the product is ready to use. The device includes free software updates for the life of the product or a minimum of 5 years starting from date of purchase..
#5: Produktvideo & Tipps
- Produktvideo: -
- Hinweise für den Start und Umgang mit RouterOS in unserem Blog: RouterOS, Reset, Netinstall, Winbox, Wiki, Supout.rif, 60GHz Ausrichtung uvm
